flechero

Lowrance HDS-7 Gen3

8 posts in this topic

After many years (12 I think) my LMS 332 finally bit the dust.  I'm looking at a Lowrance HDS-7 Gen3 Insight w/ 83/200 khz trans.  (it looks good and is on sale!) :lol:   I know NOTHING about the new technology and never even used the last unit to it's potential.



Not sure I understand... the write up says it does structure scan with the included transducer but then there is a $200 option for a structure scan transducer and another $300 for a total scan transducer.   Can anyone dumb this down for me?



I'd also appreciate any feedback from those running this unit.



Thanks!

Keith





Share this post


Link to post
Share on other sites

the transducer included will give you down scan and broadband. you can add a Lss 2 tranducer for side scan. the total scan will replace both transducers and give you down scan, side scan, and broadband. I have heard complaints about the total scan not reading with higher speeds.

Share this post


Link to post
Share on other sites

Lowrance HDS Gen 3 is a wonderful unit you will love it but selecting transducers can be tricky. So the LSS-2 Structure Scan transducer will do Side/ Down imaging only . So that means you will have a separate transducer to do sonar that transducer can be mounted shoot thru or transom mounted. The total scan transducer will do Sonar, Side/Down Imaging all out of one. The only problem with that in some cases depending on the boat its hard getting a good bottom reading on sonar while your running out of total scan because the sonar is in such a larger transducer which will displace more water there for giving you a bad reading. I suggest going with a LSS-2 then doing a sonar transducer separate in the hull or on the transom that way you will get a good sonar reading at higher speed.

1 person likes this

Share this post


Link to post
Share on other sites

Thanks for the explanation.  So to confirm, I'll need 2 transducers for full functionality? (or one really big "total scan" transducer) Both can be externally mounted? (I've had 2 shoot throughs in my life and neither worked well at all & both were dealer installed)



Thanks again!

Share this post


Link to post
Share on other sites

side scan has to be mounted externally. lss-2 and total scan transducers are both very long. lss-2 doesn't have this problem because when using side scan you should be going 3-5 mph as per the manual.

Share this post


Link to post
Share on other sites

I have a gen 3 9".  Great unit BTW.  The touch feature is great.  I rarely use the SI feature.  I am more comfortable with the sonar readings not to mention I fish shallower bodies of water.  From your post above it sounds to me that your a "sonor" guy (kind of like me).  You might want to save your money at first and just run it with the 83/200 and see if it fits your style.  If not then add the SI Stuff later.

Share this post


Link to post
Share on other sites
On 5/8/2017 at 9:00 PM, flechero said:

Thanks for the explanation.  So to confirm, I'll need 2 transducers for full functionality? (or one really big "total scan" transducer) Both can be externally mounted? (I've had 2 shoot throughs in my life and neither worked well at all & both were dealer installed)



Thanks again!

Correct the LSS-2 and the Total Scan are both pretty large but they have to mounted out side the boat. I just like having a separate sonar transducer to get a better bottom reading.

Share this post


Link to post
Share on other sites

Guys it all really depends on the boat and the installation. Here is a StarCraft 206 with the OEM 83/200 and SS3D transducers and you can see it reads bottom very well at 30+ mph, and notice that the larger SS3D transducer creates no water spout. The boat topped out at 52 mph, still reading bottom from the 83/200 although the SS3D ducer wasn't useful.

30+ MPH.JPG


Share this post


Link to post
Share on other sites
